Efficient Grass Grapple for Landscaping and Lawn Care
The root grapple is the most common attachments for a skid steer loader. It is able to help the operators handle all kinds of materials including logs, brush, rocks, trash etc. To handle all kinds of work condition, each of our root grapple is designed as rock type. We take high strength steel Q355 to ensure the solid structure, and take the wear resistance steel NM400 to make it durable.
Meanwhile, the alloy steel casting teeth are equipped on the grapple tines tips, making the root grapple more durable and got better penetration ability. The bilateral tines are designed with jagged teeth, which can help the operator load or lift the big target with a minimal amount of effort for balance, especially for the heavy or bulky target such as logs, tubes and big rocks.
All the pins on the root grapple are made from 45# steel, and the heat treatment is the necessary process at Crafts. The hard pins are able to ensure the root rake grapple open and close smoothly, even after a long term hard using.
| Model / Specification | CGG-60" | CGG-72" | CGG-84" |
| Total Length (mm) | 1530 | 1830 | 2140 |
| Total Width (mm) | 686 | 686 | 686 |
| Total Height (mm) | 965 | 965 | 965 |
| Weight (kg) | 480 | 527 | 652 |
| Grapple Open Height (mm) | 1245 | 1245 | 1245 |
| Tooth Space (mm) | 240 | 240 | 240 |
| Working Pressure (MPa) | 16 | 16 | 16 |
The root grapple is also called root rake grapple, grass grapple. As an ideal tool, it is designed for cleaning up, rake, pile and load brush, logs, and debris in your property and construction site. It can fit to the universal skid steer style quick tach system or to some tractors. Model of the well-known brands are available to match, such as Bobcat, JCB, Kubota, Case, John Deere, Komatsu etc.
